APP WSR103542 RECEPTACLE WITH DISCO

PART WSR103542 APP

MANUFACTURER Appleton

MANUFACTURER PART # WSR103542

Calculating price...

QUANTITY

About this item

Appleton Interlocked Receptacle, Grounding Style 2 Non Fused, Series: WSR, 600/250 VAC/VDC, 100 A, 75 hp, 50/60 Hz Frequency, 4 Pole, 3 Wires, NEMA 3/3R/4/4X/12 NEMA, 4 to 1/0 AWG Wire, Aluminum, 19.25 in L x 11.56 in W Dimensions

UL 98|UL 50E|UL 1682|UL 1686|UL File No. E145917|UL File No. E160652|CSA C22.2 No.4|C22.2 No. 182.1|CSA File No. 025875

Shell and extra pole grounding style 2|Without viewing window|WSR models provide a triple coated, copper-free cast aluminum enclosure that is ideal for outdoor and rugged use|Dead front design ensures that receptacle is not energized until the plug is fully inserted and the switch is engaged, locking the plug in place|Uses standard Powertite plugs|Square D* F series disconnect switches are standard on most models (some WSR models use Cutler Hammer)|Corrosion resistant, raintight, watertight|Type spring door, removable hinged, padlockable cover

Amperage Rating 100

Dimensions 19.25 in L x 11.56 in W

Frequency Rating 50/60

Horsepower 75

Material Aluminum

NEMA Rating NEMA 3/3R/4/4X/12

Number of Poles 4

Number of Wires 3

Series WSR

Type Grounding Style 2 Non Fused

Voltage Rating 600/250

Wire Size 4 to 1/0

Brand Appleton

Manufacturer Emerson Electric

Specification Sheet

Specification Sheet
