FERRAZ M60J12 SWITCH.FUS 60A J 1+2

PART M60J12 FRZ
MANUFACTURER Mersen
MANUFACTURER PART # M60J12
Calculating price...
QUANTITY

About this item

Mersen Disconnect Switch, 1+2 Position Class J Fusible, 600 VAC, 60 A, 15 hp, 30 hp, 50 hp, 50 Hz Frequency, 3 Pole, Handle Actuator, Base Mounting, Tunnel Terminal, -40 to 40 deg C, 112 mm H x 146.5 mm W x 118 mm D Dimensions, BE

RoHS Compliant|CSA Certified|UL Listed Guide WHTY|File No. E191605|UL 98|IEC 60947-3|cULus Listed|CE Certified
Multiple Configurations|Power taps|Adjustable shaft depth|Fuse monitoring|Interlocked fuse doors|15 hp at 240 VAC, 30 hp at 480 VAC, 50 hp at 600 VAC 3-phase horsepower rating
Actuator Type Handle
Amperage Rating 60
Dimensions 112 mm H x 146.5 mm W x 118 mm D
Frequency Rating 50
Horsepower 15 hp, 30 hp, 50 hp
Material BE
Mounting Type Base
Number of Poles 3
Temperature Rating -40 to 40
Terminal Type Tunnel
Type 1+2 Position Class J Fusible
Voltage Rating 600
Brand Mersen
Manufacturer MERSEN
