3M FIP 1-STEP FIRESTOP FOAM FIRESTOP FOAM 12.85

PART FIP 1-STEP FIRESTOP FOAM

MANUFACTURER 3M

MANUFACTURER PART # 7100020738

Calculating price...

QUANTITY

About this item

3M, 7100020738, Fire Barrier Rated Foam, Cartridge Container, 12.85 fl-oz Container, Composition: Part A: Polymer, Non-Halogen Flame Retardant, Phosphate, Smoke Suppressant, Water, Catalyst, Siloxanes, Part B: POLYMETHYLENE POLYPHENYLENE, ISOCYANATE, Liquid Form, 2 min Curing, Red to Brown, Earthy Odor/Scent, 50 to 120 deg F, Part A: 1.3, Part B: 1.2 Specific Gravity, Part B: >=220 deg C Flash Point, Part A: 6 to 8 pH, Part A: <10 g/L, Part B: <1 g/L VOC, Part A: 250 to 350 mPa-s, Part B: 600 to 700 mPa-s Viscosity, Applicable Materials: Blank Openings, Metal Pipe, Cables, Cable Tray, Insulated Pipe and Combination Penetrations

ACGIH Approved|ASTM Certified|ECCN: EAR99|NFPA 5000 Certified|101|IBC Certified|IRC Certified|IFC Certified|IPC Certified|IMC Certified|NEC Certified|NFPA 70|NFPA 101|NBCC Certified|UL Listed|CAN/ULC S115

Intumescent foam expands when exposed to fire|Excellent adhesion and does not require backing material in wall or floor applications|FIP 1-step shelf life is 16 months in original unopened containers from date of packaging when stored above 68 deg F and below 90 deg f|<1 cfm/sq-ft air leakage|STC RATED, Has an STC rating of 57 when tested in a STC 57-rated wall assembly|EASILY RE-ENTERABLE, Specially formulated re-enterable and repairable foam remains pliable after installation|PRIMER PAINT READY, Sealant is paintable with primer

Applicable Materials Blank Openings, Metal Pipe, Cables, Cable Tray, Insulated Pipe and Combination Penetrations

Color Red to Brown

Composition Part A: Polymer, Non-Halogen Flame Retardant, Phosphate, Smoke Suppressant, Water, Catalyst, Siloxanes, Part B: POLYMETHYLENE POLYPHENYLENE, ISOCYANATE

Container Size 12.85

Container Type Cartridge

Curing Time 2

Flash Point Part B: >=220 deg C

Form Liquid

Odor/Scent Earthy

pH Range Part A: 6 to 8

Specific Gravity Part A: 1.3, Part B: 1.2

Temperature Rating 50 to 120

Viscosity Rating Part A: 250 to 350 mPa-s, Part B: 600 to 700 mPa-s

VOC Content Part A: <10 g/L, Part B: <1 g/L

Brand 3M

Manufacturer 3M

Specification Sheet

Specification Sheet

Instruction/Installation Manual

Instruction/Installation Manual
