CEILING MOUNT SENSOR LARGE MOTION 360

PART CMR 10 - LITHONIA

MANUFACTURER Sensor Switch

MANUFACTURER PART # CMR 10

Calculating price...

QUANTITY

About this item

Sensor Switch, CMR 10, Ceiling Mount Occupancy Sensor, Line Voltage, Series: CMR, 120/277 VAC, 1/4 hp Power, PIR Sensor, 32 ft Coverage, 360 deg Viewing, 30 s to 20 min Time Delay, 50/60 Hz Response, Wired Connection, Ceiling/Flush Mounting, -10 to 71 deg C, Plastic, White, 4.55 in Dia x 1.55 in D Dimensions

UL/cUL Listed

DETECTION- Passive Infrared (PIR) occupancy detection with 360 deg coverage|RELAY- Self-contained relay (no power pack needed)|MOBILE APP- Enjoy the flexibility and convenience of programming sensor settings with your smartphone using the Sensor Switch Mobile App through camera flash programming|COVERAGE- 360 deg conical shaped pattern provides tilde 24 ft radial coverage when mounted at 9 ft, 7 to 15 ft mounting heights provide 16 to 36 ft radial coverage|TIME DELAY- Time delay feature can be set for 30 seconds to 20 min|TIMER MODE- 100 hr lamp burn-in timer mode

Color White

Connection Type Wired

Coverage 32

Dimensions 4.55 in Dia x 1.55 in D

Material Plastic

Mounting Type Ceiling/Flush

Power Rating 1/4

Response Frequency 50/60

Sensor Type PIR

Series CMR

Temperature Rating -10 to 71

Time Delay 30 s to 20 min

Type Line Voltage

Viewing Angle 360

Voltage Rating 120/277

Brand Sensor Switch

Manufacturer Acuity Brands
